Ultima™ 501

AR500 (modified) Abrasion Resistant, Alloy Wear Plate

Ultima™ 501 is furnished at a maximum hardness to resist severe abrasion and moderate impact. Typical hardness range is 475/535BHN. Typical tensile strength is 255,000 PSI. This AR500 wear plate is manufactured to modern steel making technology which incorporates; inclusion shape control, grain refinement, small batch thermal treatment, and low levels of sulfur and phosphorus. Ladle refining desulfurizes, and metal slag stirring frees unwanted gases. Micro melt practice and alloy ribbon enrichment means ideal control of analysis and physical properties. Hi-tech rolling procedures mean closer thickness tolerance, better plate density, and superior surface quality. All plates are descaled in the rolling and heat treating process. Carbon Equivalency (CE) of 54. Call or email us for a quote.

This wear plate product is intended for use in applications where a good balance of impact, toughness and abrasion resistance are required. Abrasion resistant steels are typically sold to hardness range and not a fixed chemistry.

Spacing

Key Features

Clean Steel Technology – a manufacturing process that delivers consistent steel through control and refinement of the melt.

Proprietary Chemistry – a chemistry that offers excellent cleanliness and a well defined grain structure to provide fatigue resistance when material is in service.

Electric Furnace Melt – offers greater quality control at the mill including refinement of chemistry, grain size and shape.

Vacuum Degassed – eliminates many impurities found in standard commercial grade alloys. The result is a better, cleaner, and stronger product that extends service.

Abrasion Resistant – designed to resist many forms of high abrasion and moderate levels of impact.

Deep Uniform Hardness –  quench and tempered “thru-hardened” plate that will provide consistency in overall wear performance.

Typical Mechanical Properties

Hardness, Brinell475/535 BHN
Tensile Strength255,000 P.S.I.
Yield Strength200,000 P.S.I.
Grain TypeTempered Martensite
Elongation in 2″15%
Reduction of Area41%
Carbon Equivalency (CE)54

Available Sizes

Thickness
1/4″
3/8″
1/2″
3/4″
1″
1-1/2″
2″
3″
Width and Lengths
48″ x 96″
48″ x 144″
48″ x 288″
96″ x 144″
96″ x 288″

Spacing

Applications

  • Chain Conveyors
  • Mixer Components
  • Crusher Plates
  • Cutting Edges
  • Shakeout  Liners
  • Chipper Blades
  • Screw Flights
  • Coal Chutes
  • Hammers
  • Wear Guides
  • Screens
  • Truck Bed Liners
  • Wear Rings
  • Inspection Plates
  • Bucket Liners
  • Various Hoppers
  • Fan Blades
  • Levelers
  • Ballistic Targets
  • Impact Pads

Plate Weight Chart

Thickness of PlateWeight Lbs. Per Square InchWeight Lbs. Per Square Foot
1/8″ plate.03655-1/4 #
3/16″ plate.0558#
1/4″ plate.07310-1/2#
5/16″ plate.08312#
3/8″ plate.10815-1/2#
1/2″ plate.14520-3/4#
5/8″ plate.18026#
3/4″ plate.21831-1/4#
1″ plate.29041-1/2#
1-1/4″ plate.36352#

Note: Wear plate products are designed for liner applications; they are not intended for use as self-supporting structures or lifting devices.

Supra HT™ is the past protected tradename of North American Steel Company.
